3D Mixers --- Laboratory and Production

VivTek InstrumentsSKU: 3DM-V5

Type/Scale: Laboratory
Chamber Volume: 5L
Sale price$5,750.00


Compact designing with newly designed gearing system
Full steel structure with stainless steel finishing (surface polished)
Gear box and high performance motor controlled by Delta VFD
Loading volume 50-80%
Speed 0-20RPM for lab models
Speed 0-12RPM for production models
Digital timing device controller
Over surge protection
Voltage input AC230V single phase for lab model
AC230V three phase for production model.

Model Volume Max Loading Speed Motor Dimensions
3DM-V5  5L 5kg 0-20RPM 370W 36x32x36inch
3DM-V10 10L 8kg 0-20RPM 370W 36x32x36inch
3DM-V20 20L 15kg 0-20RPM 550W 36x34x36inch
3DM-V50 50L 40kg 0-20RPM 750W 36x50x48inch
3DM-V100 100L 80kg 0-12RPM 1500W 48x60x60inch
3DM-V200 200L 150kg 0-12RPM 2200W 50x65x60inch
3DM-V500 500L 400kg 0-12RPM 5500W 72x100x65inch
