Description
Laboratory tape casting coating machine
Aluminum sample stage with vacuum sucking
Stage dimensions 380x250mm (1610) or 530x350mm (2012)
Vacuum sucked area 290x200mm (1610) or 400x290mm (2012)
Electrical heated stage 2000W/3000W up to 100 °C (HV models)
Travel distance 25-250mm (1610) or 25-400mm (2012)
Travel speed 2-200mm/s
Oil-free vacuum pump included
4.3 inch touch screen, full automatic control
Overall size 50x35x25cm, weight 30kg/70lbs (1610) or 62x45x25cm weight 45kg/100lbs (2012)
Power AC230V 15A (Heated models, HV-1610/2012) AC115V 15A (non-heated, V-1610/2012)
CAUTION: custom order product, delivery time 3-4 weeks
