Description
Double-shell stainless steel structure
Air-cooling between the inner and outer chamber walls
Maximum temperature, 1200℃
Continuous working temperature, 1150℃
Temperature is controlled at +/-1℃ with 40-segment programmable controller (PID)
Heating rate, 0-20℃
Auto over-temperature protection
Insulation material refractory alumina (1500℃ grade)
Built-in heating coils (cannot be changed), heated zone 250mm/10inch
Tube materials: quartz or alumina
Tube size: Diameter 50mm, length=600mm
Vacuum sealing flanges for two ends with fittings installed
Flexible setting as vertical or horizontal positions
Built-in gas control panel (needle valves, gauge and flow meter)
Applications: composite research, metals treatment, high temperature fine ceramic research, powder metallurgy, nano-materials
Voltage input AC115V 15A or 230V 8A single phase as specified or requested
One year limited manufacturer warranty
